产品名称：国巨高压0805/2012_贴片电容_片容_贴片电容器

所属类别：国巨高压0805/2012_贴片电容_片容_贴片电容器

产品简介：0805/2012国巨高压贴片电容,0805/2012国巨高压片容,0805/2012国巨高压贴片电容器电话：0769-89917065

详细介绍

国巨高压0805/2012

国巨高压0805/2012贴片电容参数

品牌	YAGEO/国巨	型号	0805/2012	介质材料	陶瓷(瓷介)
应用范围	高压	外形	方块状	功率特性	中功率
频率特性	中频	调节方式	微调	引线类型	无引线
允许偏差	±10（%）	耐压值	250（V）	等效串联电阻(ESR)	0（mΩ）
标称容量	0.47pF~820pF（uF）	损耗	0	额定电压	50（V）
绝缘电阻	0（mΩ）	温度系数	0

国巨高压0805/2012尺寸示意图 18680070280

国巨高压0805/2012尺寸结构示意图

国巨高压0805/2012 贴片电容片容贴片电容器特性

NP P0 0/ / X7 7R R DI IE EL LE E CT TR RI I C C AP P A CI IT T OR RS S; ; NI I/ /S SI I N T TE ER R MI I N AT TI I O NS S
Unless otherwise specified, all test and measurements shall be made under standard atmospheric conditions
for testing as given in 5.3 of IEC 60068-1:
- Temperature: 15 °C to 35 °C
- Relative humidity: 25% to 75%
- Air pressure: 86 kPa to 106 kPa
Before the measurements are made, the capacitor shall be stored at the measuring temperature for a time
sufficient to allow the entire capacitor to reach this temperature.
The period as prescribed for recovery at the end of a test is normally sufficient for this purpose.

Table 14 DESCRIPTION			VALUE
Capacitance range			0.47 pF to 1 pF
Capacitance tolerance NP0 C < 10 pF C > 10 pF			±0.25 pF, ±0.5 pF ±2%, ±5%
X7R			±5% ⑴，±10%, ±20%
Dissipation factor (D.F.) NP0 C < 30 pF C > 30 pF			< 1 / ( 400 + 20C ) < 0.1 %
X7R < 10V			< 5 %
16 V			<2.5%
Exception: 0402 > 27 nF;	0603 > 220 nF;	0805 > 680 nF	< 5 %
25 V			<2.5%
Exception: 0402 > 10 nF;	0603 > 47 nF;	0805 > 220 nF; 1206 > 1 ^F	<3.5%
0402 > 56 nF;	0805 > 680 nF		< 5 %
> 50 V			< 2.5 %
Exception: 0603 > 47 nF			< 3.0 %
Insulation resistance after 1 minute at Ur (DC)		IR > 10 GQ or I.R x C > 500 seconds whichever is less
Maximum capacitance change as a function of temperature (temperature characteristic/coefficient): NP0 X7R			±30 ppm/°C ±15%
Operating temperature range: NP0/X7R			-55 °C to +125 °C
